LiftMaster LA400PKGU Gate Opener, Liftmaster LA400 Residential DC Linear Swing Gate Operator Chamberlain DOUBLE UNIT
|
|
 |
One of our most popular swing gate operators, just got even better in delivering unsurpassed performance and secure access to your property. Access your property like never before.
With MyQ® Technology you can monitor and control your gate from anywhere and get in quickly and securely with the built-in interference eliminating Security+ 2.0™ radio. Best in class power management technology extends battery backup for up to 97 days* without recharging, providing greater security and reliability. No one else can offer you that peace of mind.
The LA400PKGU is capable of operating gates up to 16 ft.
Gate Size rated for gates up to 16 ft. in length or weighing up to 850 lbs.
An on-board radio receiver is included with the LA400PKGU. Exclusive
from Chamberlain, this provides a single remote control solution
for gates and additional access points.
Unrivaled Performance, Safety and Accessibility Built to deliver unsurpassed safety and performance, our 2016 UL Listed Gate Operators and Monitored Safety Entrapment Devices provide peace of mind for every gate application.
 Manual
Spec Sheet
Note: The Per UL325-2016 all gate operators sold in the USA after February 2016 will be required to have a monitored safety photo cell to prevent accidental crushing or entrapment.
Compatible photo cell More Information here
|
LiftMaster LA400PKGU Residential DC Linear Gate Operator / Opener (Double Unit) -- Add To Cart For Special Pricing - To Low To Advertise

LiftMaster LA400-1PKG / New Model LA400PKGU Residential DC Linear Gate Operator / Opener (Single Unit) -- Add To Cart For Special Pricing - To Low To Advertise
LiftMaster LA400 / New Model LA400PKGU Residential DC Linear Gate Operators / Openers ( Arm only ) -- Add To Cart For Special Pricing - To Low To Advertise
LiftMaster LA400-S / New Model LA400PKGU Residential DC Linear Gate Operators / Openers ( Second Arm only ) -- Add To Cart For Special Pricing - To Low To Advertise
Connectivity
• MyQ Technology enables you to securely monitor and control your gate
operator and houselights with your smartphone for greater peace of mind.
• Alerts can be received as email or pop-up (push) notifications on your mobile device so that you always know the status of your gate operator.
• MyQ Mobile App is a free download with no annual activation fee.
Performance
• Battery Backup safeguards your property by providing up to 400 cycles* or up to 97 days* of standby power when the power is down.
• Solar Ready Ultra-Reliable System delivers power when you need it most to operate the gate and is extremely power efficient at all other times to maximize solar performance.
• Heavy-Duty Cast Aluminum Housing DC Motor powerful enough to perform in the most demanding applications. Soft start/stop operation extends operator and hardware life for heavy-duty gate use.
• Gate Size rated for gates up to 16 ft. in length or weighing up to 850 lbs.
Safety and Security
• Security+ 2.0™ Patented Multi-Frequency Secure Radio Technology virtually eliminates interference and offers 2X the range of standard remotes so you can access your home quickly and safely.
• Safety Inputs are provided for the addition of safety reversing devices. Each entrapment point should be protected with its own device.
• UL/cUL Listed tested to the most stringent industry guidelines.
| Usage Classification |
Class I, II, III, & IV |
| Main AC Supply |
120 Vac, .5 Amps (6.5 Amps including Accessory Outlets) |
| System Operating Voltage |
24 Vdc Battery Run / Direct Plug-in Transformer Charge |
| Accessory Power |
24 Vdc, 500mA max. for ON + SW (switched) |
| Solar Power Max |
24 Vdc at 60 watts max. |
| Maximum Gate Weight |
850 lbs. (385.6 kg) / 10 ft (3.0 m)
750 lbs. (340.2 kg) / 12 ft (3.7 m)
650 lbs. (294.8 kg) / 14 ft (4.3 m)
550 lbs. (249.5 kg) / 16 ft (4.9 m) |
| 90 Degree Travel Time |
15-18 seconds |
| Maximum Travel Range |
115 degrees |
| Maximum Daily Cycle Rate |
100 cycles / day |
| Maximum Duty Cycle |
4 min on |
| Operating Temperature |
-20°C to 60°C (-4°F to 140°F) |
| Expansion Board |
Optional |
| Inherent Entrapment Protection (Type A) |
Dual - RPM and Current Sense |
| External Entrapment Protection (Type B1 and/or Type B2) |
3 inputs per board - any combination of up to 3 photoelectric sensors and up to 2
edge sensors |
|
