| Item |
Description |
Part Number |
Price |
| 1 |
Gear Reducer Size 40 60:1 |
50-027 |
|
| 2 |
20 Pin Edge Connector |
50-039 |
|
| 3 |
40 b 12 7/8" Sprocket |
50-050 |
|
| 4 |
Limit Switch 00h-3 |
50-069 |
|
| 5 |
# 40 Drive Chain |
50-084 |
|
| 6 |
# 6 x 1" Machine Screw |
50-091 |
|
| 7 |
3/8-16 x 1 1/2" Hex Head Bolt |
50-092 |
|
| 8 |
5/16-18 x 3/4" Hex Head Bolt |
50-095 |
|
| 9 |
5/16" Lock Washer |
50-096 |
|
| 10 |
5/16" Flat Washer |
50-097 |
|
| 11 |
3/8-18 Hex Head Lock Nut |
50-103 |
|
| 12 |
5/16" Hex Head Nut |
50-104 |
|
| 13 |
# 6 Hex Head Nut |
50-105 |
|
| 14 |
# 6 x 3/8" Machine Screw |
50-107 |
|
| 15 |
1/2-14 x 2 1/2" Hex Head Bolt |
50-110 |
|
| 16 |
1/2-14 x 3 1/2" Hex Head Bolt |
50-111 |
|
| 17 |
1/2" Flat Washer |
50-112 |
|
| 18 |
1/2-14 Nylon Lock Nut |
50-113 |
|
| 19 |
1/4-20 Socket Head Screw |
50-114 |
|
| 20 |
Polyethylene Cup Cover |
50-115 |
|
| 21 |
1" x 2" x 32" Rectangular Metal Tube |
50-117 |
|
| 22 |
1" x 2" x 42" Rectangular Metal Tube |
50-118 |
|
| 23 |
Channel |
50-126 |
|
| 24 |
2 1/2" Torque Limited Arbor |
50-127 |
|
| 25 |
2 1/2" Torque Limited Washer |
50-128 |
|
| 26 |
2 1/2" Torque Limited Friction Disc |
50-129 |
|
| 27 |
2 1/2" Torque Limited Tension Washer |
50-130 |
|
| 28 |
1-3/4" Torque Limited Nut |
50-131 |
|
| 29 |
Access Door Lock |
50-149 |
|
| 30 |
Warning Sign for Gate |
50-151 |
|
| 31 |
Horn Alarm |
50-168 |
|
| 32 |
3 1 1/2" Clamp Release |
50-172 |
|
| 33 |
Torque Limited Bushing |
50-181 |
|
| 34 |
Limited Switch Bracket |
50-183 |
|
| 35 |
1/2 Hp 115 VAC Electric Motor |
50-200 |
|
| 36 |
Capacitor |
50-205 |
|
| 37 |
Rocker Switch |
50-215 |
|
| 38 |
3/4" Sealed Ball Bearing |
50-247 |
|
| 39 |
3/4" Collard Shaft |
50-253 |
|
| 40 |
1/4" x 5" Key Way |
50-263 |
|
| 41 |
3/16" x 3/4" Key Way |
50-265 |
|
| 42 |
1 1/2" UHMW Spacer |
50-275 |
|
| 43 |
#8 Self-Tap Sheet Metal Screw |
50-295 |
|
| 44 |
Radio Receiver Terminal |
50-299 |
|
| 45 |
120/240 Intelligate Transformer |
50-304 |
|
| 46 |
1/2" x 1-1/2" Hex Head Bolt |
50-337 |
|
| 47 |
1" x 2" Plastic Cap |
50-339 |
|
| 48 |
10 Ga Heavy Duty Metal Chassis |
50-401 |
|
| 49 |
Board Lexan Glass Cover |
50-402 |
|
| 50 |
Polyethylene Cover |
50-403 |
|
| 51 |
3/4" x 10" Limit Switch Shaft |
50-404 |
|
| 52 |
40A27 Sprocket |
50-405 |
|
| 53 |
3/4" Limit Switch Cam |
50-406 |
|
| 54 |
1/2" x 1" Cast Iron Pulley |
50-407 |
|
| 55 |
6" Aluminum Pulley |
50-408 |
|
| 56 |
4L V Belt #250 |
50-409 |
|
| 57 |
1/4" x 1 1/2" x 10" Ext. Gate Bracket |
50-419 |
|
| 58 |
#6 x 2" Machine Screw |
50-529 |
|
| 59 |
120 VAC Double Outlet |
50-511 |
|
| 60 |
#6 x 1/4" Machine Screw |
50-526 |
|
| 61 |
5/16" Socket Head Screw |
50-539 |
|
| 62 |
Internal Gate Bracket Swing Arm |
50-546 |
|
| 63 |
Access Door Frame |
50-559 |
|
| 64 |
Access Door |
50-560 |
|
| 65 |
1 1/2" x 1 1/2" x 3/4" Sq. Pivot |
50-563 |
|
| 66 |
1/2" x 1 1/2" Iron Pulley |
50-564 |
|
| 67 |
5/16" x 1 1/2" Knob |
50-565 |
|
| 68 |
5/16" x 1/2" Knob |
50-566 |
|
| 69 |
Instruction Manual |
50-569 |
|
| 70 |
Intelligate Control Board |
50-777 |
|
