| Item |
Description |
Part Number |
Price |
| |
Complete Enclosure with Door Assembly |
2120-359 |
|
| 1 |
Enclosure without Door |
2120-144 |
|
| |
Complete Door and Lock Assembly |
2120-360 |
|
| |
C-Face Brake, 115/230V |
2500-2192 |
|
| |
C-Face Brake, 460V |
2500-2193 |
|
| 5 |
Rail Assembly |
2110-265 |
Our Price: $147.61
 |
| 15 |
Spacer Plate |
2100-573 |
Our Price: $13.48
|
| |
Back Brace |
2100-661 |
Our Price: $21.19
|
| 12 |
Drive Shaft, 1" |
2100-1738 |
Our Price: $70.26
|
| 48 |
Retaining Ring |
2400-501 |
Our Price: $2.14
|
| 9 |
Bearing, 1" |
2200-274 |
Our Price: $65.84
|
| 43 |
Pillow Block Retaining Plate |
2100-1737 |
Our Price: $9.95
|
| 40 |
Sprocket, 48 B 15, 1" bore |
2200-042 |
Our Price: $37.02
|
| |
Shaft Collar, 1" |
2200-015 |
Our Price: $7.17
|
| 7 |
Torque Limiter Assembly, 5 1/2” |
2120-388 |
Our Price: $190.04
|
| 7A |
Plate with Solid Pin Groove |
2100-1650 |
Our Price: $51.15
|
| 7B |
Keyed Plate |
2100-1661 |
Our Price: $40.87
|
| 7C |
Friction Disc (pair) |
2300-390 |
Our Price: $51.90
|
| 7D |
Belleville Washer |
2200-817 |
Our Price: $13.16
|
| 7E |
Belleville Washer Retaining Disc |
2100-1621 |
Our Price: $51.79
|
| 7F |
Adjustment Nut |
2100-1622 |
Our Price: $3.75
|
| 7G |
Brass Tipped Set Screw |
2400-407 |
Our Price: $2.00
|
| 7H |
Dowel Pin |
2400-416 |
Our Price: $7.38
|
| 7I |
Woodruff Key |
2100-529 |
Our Price: $2.14
|
| 8 |
Sprocket, 40-A-48 |
2200-555 |
|
| 42 |
Drive Sprocket, 50-B-20, 1” Bore |
2200-886 |
Our Price: $17.55
|
| |
Gear Reducer/Disconnect Assembly |
2110-363 |
Our Price: $563.14
|
| 2 |
Gear Reducer, 10:1 |
2200-551 |
Our Price: $415.41
|
| 19 |
Shifter Lever Assembly |
2120-132 |
Our Price: $36.93
|
| 18 |
Shifter Lever Fulcrum Assembly |
2110-362 |
Our Price: $21.83
|
| 37 |
Shifter Lever Rod |
2100-551 |
Our Price: $9.20
|
| 38 |
Pal Nut |
2400-169 |
Our Price: $2.00
|
| 20 |
Locking Lever Plate |
2100-1133 |
Our Price: $21.83
|
| 28 |
Locking Lever |
2100-910 |
Our Price: $11.02
|
| 41 |
Shifter and Locking Lever Spring |
2200-291 |
Our Price: $4.71
|
| 14 |
Shaft Collar, 1" |
2200-014 |
Our Price: $7.17
|
| 11 |
Sprocket, 40 A 24, with Bearing |
2110-364 |
Our Price: $37.02
|
| 30 |
Disconnect Collar, 1" (keyed) |
2200-549 |
Our Price: $7.17
|
| 31 |
Shifter Block |
2110-131 |
Our Price: $36.93
|
| |
Key, 1/4" x 1/4" x 2 1/4" |
2400-133 |
Our Price: $2.00
|
| 32 |
Disconnect Spring |
2200-115 |
Our Price: $11.02
|
| 44 |
Stop/Reset Button & Bracket Assembly |
2510-248 |
Our Price: $31.78
|
| |
Stop/Reset Button Mounting Bracket |
2100-1760 |
Our Price: $3.75
|
| |
Stop/Reset Button |
2500-1495 |
|
| 45 |
Power On/Off Disconnect Assembly with Receptacles (115V Models only) |
2510-251-D |
Our Price: $46.76
|
| |
115VAC Duplex Receptacles only |
2500-1956 |
Our Price: $17.55
|
| |
115VAC Switch only |
2500-1957 |
Our Price: $29.21
|
| |
Power On/Off Disconnect Assembly
for 230V Models |
2510-252-D |
Our Price: $51.15
|
| |
230VAC Switch only |
2500-2205 |
Our Price: $30.71
|
| |
Power On/Off Disconnect Assembly
for 3-Phase Operators |
2510-294 |
Our Price: $51.15
|
| |
Power Switch only |
2500-034 |
|
| 46 |
Mounting Plate |
2100-1756 |
Our Price: $42.27
|
| 47 |
Accessory Shelf for single phase models only |
2100-1781 |
Our Price: $21.94
|
| 33 |
Fender Washer, 3/8" |
2400-308 |
Our Price: $2.00
|
| 34 |
Flat Washer, 3/8" |
2400-017 |
Our Price: $2.00
|
| 35 |
Lock Washer, 3/8" |
2400-016 |
Our Price: $2.00
|
| 36 |
HHCS, 3/8"-16 x 2 1/2" |
2400-207 |
Our Price: $2.00
|
| 16 |
Idler Assembly |
2110-700 |
Our Price: $58.92
|
| |
UHMW Idler Wheel |
2300-697 |
Our Price: $21.94
|
| |
Idler Shaft |
2100-1731 |
Our Price: $5.14
|
| 6 |
Rotary Limit Box Assembly |
2520-453 |
Our Price: $164.32
|
| |
Limit Switch |
2500-764 |
Our Price: $40.34
|
| |
Standard Limit Shaft |
2100-057 |
Our Price: $21.83
|
| |
Limit Nut |
2200-030 |
Our Price: $3.85
|
| |
Detent Plate |
2100-261 |
Our Price: $3.85
|
| |
Limit Box Enclosure with Cover |
2110-162 |
Our Price: $50.40
|
| |
Limit Box Cover only |
2100-756-PLT |
|
| |
Flange Bearing, 1/2" ID |
2200-029 |
Our Price: $6.31
|
| |
Push-on Nut |
2400-029 |
Our Price: $2.14
|
| |
Limit Drive Sprocket, 48-B-15, 1” bore |
2200-042 |
Our Price: $37.02
|
| 39 |
For drives up to 34 feet wide: Limit Box Sprocket, 48-B-10, 1/2” bore |
2200-008 |
Our Price: $21.83
|
| |
For drives up to 34 feet wide: #48 Chain, 25 Links |
2200-922 |
Our Price: $8.88
|
| |
For drives from 35 to 49 feet wide: Limit Box Sprocket, 48-B-15, 1/2” bore |
2200-041 |
Our Price: $25.25
|
| |
For drives from 35 to 49 feet wide: #48 Chain, per foot, 27 Links |
2200-200 |
Our Price: $9.31
|
| |
For drives 50 to 65 feet wide: Limit Box Sprocket, 48-B-20, 1/2” bore |
2200-276 |
Our Price: $28.68
|
| |
For drives 50 to 65 feet wide: #48 Chain, per foot, 29 Links required |
2200-654 |
Our Price: $5.56
|
| |
For drives over 65 feet wide: Limit Box Sprocket, 48-B-30, 1/2” bore |
2200-432 |
Our Price: $81.29
|
| |
For drives over 65 feet wide: #48 Chain, per foot, 32 links required |
2200-654 |
Our Price: $5.56
|
| |
#48 Master Link |
2200-010 |
Our Price: $2.14
|
| |
#40 Chain, 37 Links |
2200-605 |
Our Price: $21.83
|
| |
#40 Master Link |
2200-006 |
Our Price: $2.57
|
| 17 |
Rain Cover |
2100-657 |
|
| 24 |
#50 Roller Chain, per foot |
2200-221 |
Our Price: $8.88
|
| |
#50 Master Link |
2200-111 |
Our Price: $3.85
|
| 25 |
Chain Pin |
2100-258 |
Our Price: $8.88
|
| 26 |
Tension Spring |
2200-306 |
Our Price: $5.56
|
| 22 |
Gate Bracket |
2100-2007 |
Our Price: $27.07
|
| 27 |
Hex Nut, 1/2" |
2400-090 |
Our Price: $2.00
|
| 23 |
Gate U-Bolt |
2400-170 |
Our Price: $4.71
|
| 21 |
Mounting U-Bolt |
2400-038 |
Our Price: $7.17
|
| |
Alarm, 24VAC |
2500-867 |
|
| |
3-Button Station with Lead Wires |
2510-064 |
|
