All Star Model LP1000

Item Description Part Number Price
1 Cover, Leader Plus (Not Shown) 010432
2 V-Belt, 4L310 111814
3 Lock Assembly 102076
4 Lock Solenoid 102551
5 Lock Pin Bracket 010418
6 Lock Pin 102093
6a Lock Pin ASSY,CMPLT, Leader + 103572
7 Rubber Grommet 010423
8 Retaining Ring 010422
9 Lock Spring 102075
10 Pulley, Lock Plate 102077
11 Set Screw 010025
12 18 Tooth Sprocket 110131
13 Speed Reducer Assembly, Leader 102771
14 Limit Nut 010606
15 Limit Switch Assembly, Leader 103829
16 Limit Detent Plate 104444
17 Limit Switch 005063
18 Bolt, 5/8-18 x 4L 106430
19 Pulley, Idler, UHMW, 3.5 OD 104395
20 1/2 HP Motor 010172
21 Motor Pulley 010213
22 Screw, HHCS, 5/16-18 x 1, ZI 006030
23 Handy Box, 4 x 4 010444
24a Box Cover, 4 x 4, Duplex, Raised 111885
24b Box Cover, 4 x 2, Duplex, Raised 111886
25 Frame, Leader 111244
26 Control Box Cover 110103
27 Motor Control Board (Not Shown) 110001
28 Control Box Assembly, Leader 110101
not shown Power Switch/Outlet Combo 110132
not shown Transformer,115-24V,40 VA 005244
not shown Cover Lock (Not Shown) 102776
not shown Sign, Gate, Warning/OSHA 103647
not shown Sign, Gate, Warning/OSHA/Clear 103671
not shown Installation & Owner’s Manual 110136
