Multi-Code 3083 2-Button Keychain Gate Garage Remote MultiCode 308301 MCS308301 Lot of 10-- $189.00

|
 |
The MultiCode 308301 2-Channel Key Ring Transmitter is a miniature style transmitter designed for automatic door and gate operator applications.
This transmitter is a two-channel device. Pressing the left button on the transmitter will send a channel one signal. Pressing the right button on the transmitter will send a channel two signal. The buttons feature raised dimples for easy, or vision-impaired identification. The transmitter has a red test/operate indicator and is powered by a 12-volt battery. A molded-in hole in the case is for attaching the transmitter to a key ring.
The transmitter is Multi-Code format with two 10-position coding switches providing 1,024 possible codes for each channel. Independent coding supports activation of a common gate and a private door. The transmitter will only activate receivers set with the same code.
The Multi-Code 308301 is compatible with 300 MHz Multi-Code receivers and Model 109950 and 302850 receivers.
 Manual
Spec Sheet
Features
- Compatible with 300 MHz Multi-Code receivers
- Powered by 12-volt battery
- Easy access to battery and coding switches
- 1,024 codes for each channel
- RF frequency: 300 MHz
- 1.5" W x 2.5" H x 0.625" D
- Order number: MCS308301
|
