Linear MCS412001 Multi-Code 2-Channel Visor Transmitter 10 LOT -- $192.00 (most Popular)

|
 |
The MultiCode 412001 2-Channel Visor Transmitter is a poratble transmitter designed for automatic door and gate operator applications.
This transmitter is a two-channel device. Pressing the left button on the transmitter will send a channel one signal. Pressing the right button on the transmitter will send a channel two signal. The buttons feature raised dimples for easy, or vision-impaired identification. A visor clip is included. The transmitter is powered by a 9-volt battery and has a test/operate indicator.
The transmitter is Multi-Code format with two 10-position coding switches providing 1,024 possible codes for each channel. Independent coding supports activation of a common gate and a private door. The transmitter will only activate receivers set with the same code.
The Multi-Code 412001 2-Channel Visor Transmitter is compatible with 300 MHz Multi-Code receivers and Model 109950 and 302850 receivers.
Features
- Compatible with 300 MHz Multi-Code receivers
- Supplied with visor clip
- Powered by 9-volt battery
- Easy access to battery and coding switch
- 1,024 codes
- RF frequency: 300 MHz
- 3.75" W x 2.5" H x 0.875" D
- Order number: MCS412001
 Manual
Spec Sheet
Please Make Sure on the Frequency MHz Needed! |
