GATE OPENER BRANDS





OSCO Slide Gate Opener Parts - HSLG

OSCO Slide Gate Opener Parts - HSLG



Item Description Part Number Price
  Intermediate Shaft Assembly 2110-240 Our Price: $110.41
10 Pulley Shaft 2100-765 Our Price: $51.15
14 Sprocket, 41 B 9, 5/8" Bore 2200-213 Our Price: $21.83
9 Double Pulley, 7" 2200-309 Our Price: $41.56
11 Set Collar Set, 5/8" 2200-233 Our Price: $7.60
92 Precision Bearing, 5/8" 2200-215 Our Price: $8.03
72 Key, 3/16" x 1 1/2" 2200-333 Our Price: $2.00
71 Key, 3/16” x 1 1/4” 2100-1750 Our Price: $7.38
12 Brake Disc 2100-547 Our Price: $21.83
  Clutch Shaft Assembly 2110-274 Our Price: $109.69
30 Clutch Shaf 2100-1008 Our Price: $40.17
28 Sprocket, 41 A 36, 1" Bore 2200-294 Our Price: $38.63
31 Clutch Hub (Pinned) 2100-669 Our Price: $21.83
78 Clutch Hub (Keyed) 2100-1007 Our Price: $21.83
79 Clutch Facing 2100-564 Our Price: $6.74
32 Clutch Spring 2200-306 Our Price: $5.56
33 Hex Nut, 5/8"-18 2400-061 Our Price: $2.00
89 Jam Nut, 5/8"-18 2400-062 Our Price: $2.00
81 Thrust Washer, 1" x 1/8" 2400-187 Our Price: $2.00
  Roll Pin, 3/16" x 1 3/8" 2400-088 Our Price: $2.14
27 Sprocket, 41 B12, 5/8" Bore 2200-292 Our Price: $26.96
  Precision Bearing, 5/8" 2200-215 Our Price: $8.03
11 Set Collar, 5/8" 2200-233 Our Price: $7.60
70 Key, 3/16" x 1 1/4" 2400-238 Our Price: $2.00
82 Key, 3/16” x 1/4” 2400-273 Our Price: $2.00
  Output Shaft Assembly 2110-236 Our Price: $194.30
15 Output Shaft, 1" 2100-917 Our Price: $46.76
20 Sprocket, 41 A 24 with Bearing 2220-022 Our Price: $43.87
93 Bearing only for 41 A 24 Sprocket 2200-119 Our Price: $7.17
21 Shifter Block with Pins 2110-131 Our Price: $36.93
25 Pillow Block Bearing, 1" 2200-274 Our Price: $65.84
97 Pillow Block Retaining Plate 2100-1737 Our Price: $9.95
37 Set Collar, 1" x 3/8" LTB 2200-014 Our Price: $7.17
26 Set Collar, 1" x 5/8" LTB 2200-091 Our Price: $7.17
73 Key, 1/4” x 1 1/2” 2400-201 Our Price: $2.35
16 Sprocket, 40 B 18, 1" Bore 2200-267 Our Price: $43.66
  Spring Pin, 3/16" x 1" (Predrilled for Pillow Block) 2400-026 Our Price: $2.00
18 Idler Assembly 2110-700 Our Price: $58.92
6 Rotary Limit Box Assembly 2520-173R Our Price: $115.12
  Limit Switch 2500-764 Our Price: $40.34
  Standard Limit Shaft 2100-057 Our Price: $21.83
  Limit Nut 2200-030 Our Price: $3.85
  Detent Plate 2100-261 Our Price: $3.85
  Limit Box Enclosure with Cover 2110-162 Our Price: $50.40
  Limit Box Cover only 2100-756 Our Price: $11.02
  Flange Bearing, 1/2" ID 2200-029 Our Price: $6.31
  E-Ring, 1/2” 2200-193 Our Price: $2.00
  Spring Washer, 1/2” 2400-203 Our Price: $2.00
7 Limit Drive Sprocket, 48-B-10, 1/2” Bore
For Drives up to 30 feet wide:
2200-008 Our Price: $21.83
  Limit Box Sprocket, 48-B-10, 1/2” Bore 2200-008 Our Price: $21.83
  Chain, per foot, 27 Links required
For Drives from 31 to 45 feet wide:
2200-654 #48
  Limit Box Sprocket, 48-B-15, 1/2” Bore 2200-041 Our Price: $25.25
  #48 Chain, per foot, 29 Links required
For Drives over 45 feet wide:
2200-654 Our Price: $5.56
  Limit Box Sprocket, 48-B-20, 1/2” Bore 2200-276 Our Price: $28.68
  #48 Chain, per foot, 30 Links required 2200-654 Our Price: $5.56
34 #40 Chain, per foot 2200-202 Our Price: $7.17
36 U-Bolt, 4 5/8" 2400-038 Our Price: $7.17
  Three-Button Station with Lead Wires 2510-064
102 Control Box Mounting Plate 2100-1756 Our Price: $42.27
103 Accessory Shelf for Single Phase Models only 2100-1781 Our Price: $21.94

Motors

95 1/2 HP, 115V, 1 Phase 2500-2307 Our Price: $314.84
  1/2 HP, 208/230V, 1 Phase 2500-2308 Our Price: $314.84
  3/4 HP, 115V, 1 Phase 2500-2309 Our Price: $48.18
  3/4 HP, 208/230V, 1 Phase 2500-2310 Our Price: $43.19
  1 HP, 115V, 1 Phase 2500-2311 Our Price: $382.17
  1 HP, 208/230V, 1 Phase 2500-2312 Our Price: $69.29
  1/2 HP, 208/230/460V, 3 Phase 2500-2313 Our Price: $348.06
  3/4 HP, 208/230/460V, 3 Phase 2500-2314 Our Price: $370.20
  1 HP, 208/230/460V, 3 Phase 2500-2315 Our Price: $386.85

Capacitors

  Capacitor for 2500-2307 Motor 2500-2336 Our Price: $93.06
  Capacitor for 2500-2308 Motor 2500-2337 Our Price: $76.87
  Capacitor #1 for 2500-2309 Motor 2500-1926 Our Price: $48.18
  Capacitor #2 for 2500-2309 Motor 2500-1930
  Capacitor for 2500-2310 Motor 2500-1931 Our Price: $43.19
  Capacitor for 2500-2311 Motor 2500-2338 Our Price: $117.34
  Capacitor for 2500-2312 Motor 2500-1932 Our Price: $69.29

Magnetic Brakes (includes 41, 42, 44, 45 and 46

40 115V 2510-398 Our Price: $78.78
  230V 2510-399 Our Price: $78.78
  460V 2510-400 Our Price: $134.48
41 Brake and Puck Assembly 2220-983
42 Brake Solenoid, 230 VAC 2500-177 Our Price: $40.46
  Brake Solenoid, 115 VAC 2500-178 Our Price: $40.46
  Brake Solenoid, 460 VAC 2500-1351 Our Price: $90.93
44 Brake Spring (short) 2200-243
46 Brake Rod 2100-548 Our Price: $8.45
45 Brake Plate 2100-541 Our Price: $5.56
13 Bracket for Brake 2100-2091 Our Price: $10.91
1 Enclosure Assembly Complete with Door 2120-359-BT Our Price: $589.20
  Door Assembly only 2120-360-BT Our Price: $197.00
  Door Assembly only 2120-360-BT Our Price: $197.00
  Lock Assembly with Keys 2110-643 Our Price: $42.45
  Replacement Key 2200-540 Our Price: $7.17
53 Rail Assembly 2110-234 Our Price: $147.61
3 Spacer Plate 2100-573 Our Price: $13.48
94 Double Pulley, 2" 2200-207 Our Price: $28.57
29 #41 Chain, 30 Links 2400-149 Our Price: $11.02
22 Shifter Lever 2120-132 Our Price: $36.93
23 Locking Disconnect Lever 2100-910 Our Price: $11.02
24 Disconnect Spring 2200-291 Our Price: $4.71
19 Rain Cover 19 2100-657-BT Our Price: $35.31
75 Roll Pin 2400-088 Our Price: $2.14
87 Gate Bracket 2100-2007 Our Price: $27.07
88 U-Bolt, 3" 2400-170 Our Price: $4.71
84 Chain Tension Bolt, 1/2" 2100-258 Our Price: $8.88
85 Clutch/Chain Tension Spring 2200-306 Our Price: $5.56
86 Hex Nut, 1/2"-13 (4) 2400-090 Our Price: $2.00
  Flat Washer, 1/2" 2400-045 Our Price: $2.00
  Alarm, 24VAC 2500-867
5 V-Belt, 28" 2200-234
  Bearing Spacer 2100-553 Our Price: $11.02
90 #41 Chain, per foot (20 links required) 2200-150 Our Price: $6.74
76 #41 Master Link 2200-027 Our Price: $2.57
  Side Plate, 1/2" 2100-656-BT Our Price: $8.88
  Side Plate, 3/16” 2100-059-BT Our Price: $3.85
96 #40 Master Link 2200-006 Our Price: $2.57
8 #48 Chain, per foot (27 links required) 2200-654 Our Price: $5.56
77 #48 Master Link 2200-010 Our Price: $2.14
91 5/16-18 U-Nut (4) 2400-422 Our Price: $2.03
100 Stop/Reset Button and Bracket Assembly 2510-248 Our Price: $31.78
  Stop/Reset Button Mounting Bracket 2100-1760 Our Price: $3.75
  Stop/Reset Button 2500-1495
101 Power On/Off Disconnect Assembly
with Receptacles (115V Models only)
2510-251-D Our Price: $46.76
  115VAC Duplex Receptacles only 2500-1956 Our Price: $17.55
  115VAC Switch only 2500-1957 Our Price: $29.21
  Power On/Off Disconnect Assembly
for 230VAC Models
2510-252-D Our Price: $51.15
  230VAC Switch only 2500-2205 Our Price: $30.71
  Power On/Off Disconnect Assembly
for 3 Phase Operators
2510-294 Our Price: $51.15
  Power Switch only 2500-034
